To create a new path

  1. Click the Add Path tool .
  2. Display the Enfocus Inspector.
    See Opening the Enfocus Inspector dialog
  3. Position the pointer in the PDF document where you want to create the first anchor point and click.
  4. Position where you want the first segment to end and click again.

    You have now drawn a segment between the two anchor points.





    1. First anchor point

    2. Segment

    3. Center point

    4. Second anchor point and pointer

  5. Click at other positions to add new anchor points and thus create additional seg­ments.
    Note: To create a curved segment, click at a position, hold down the mouse button and drag.
  6. To complete the path, do one of the following:
    • Click any tool other than the Add Path tool
    • Press ESC.
    • Click Close Path in the Enfocus Inspector.
Parent topic: Creating a new path
